AC COMPRESSORLocation on: HOME > Products>AC COMPRESSOR

  • R410A、R134a COMPRESSOR (ACC 2)

    If you have any question,Please call us： jim@fluorotech.com.cn







Available for air-conditioner dehumidifier and industrial water chillers,etc.

COMPRESSOR PERFORMANCE PARAMETERS:

REFRIGERANT MODEL POWER SUPPLY CYLINDER
VOLUME
（cm³）		 NOMINAL
CAPACITY		 INPUT COP Capacitor
uf/450VAC
W Btu/h POWER(W) (W/W)
VERTICAL R410A JVA075T 115V/60HZ 7.5 2060 7025 725 2.80 40
JVA075K 220-240V/50HZ 1660 5661 615 2.80 20
JVA090T 115V/60HZ 8.9 2440 8320 870 2.80 40
JVA090K 220-240V/50HZ 1970 6718 700 2.80 20
R134a JVB075K* 220-240V/50HZ 7.5 870 2967 295 2.95 15
JVB092K* 9.2 1060 3615 360 2.95 15
JVB132K* 13.2 1530 5217 520 2.95 20
JVB075T* 115V/60HZ 7.5 1050 3581 350 3.00 15
JVB092T* 9.2 1250 4262 415 3.00 15
JVB132T* 13.2 1850 6309 615 3.00 20

NOTE: In developing.(The displacement could be adjusted or developed as your requirement)
TEST CONDITIONS:

APPLICATION AMBIENT TEMP. EVAP. TEMP. RETURN GAS TEMP. SUBCOOLING TEMP. CONDENSING TEMP.
HIGH TEMP 35℃ 7.2℃ 35℃ 46.1℃ 54.4℃
