  • DC VARIABLE SPEED COMPRESSOR (ACC 6)

    If you have any question,Please call us： jim@fluorotech.com.cn







DC compressor 12V/24V/48V/72V has the character of safety. Energy-saving and environmental protection. It is widely used in air conditionting system of truck sleeper, electricvehicle,special vehicle,vessel,heat pump、solar air conditioner and telecom-shelter etc.

COMPRESSOR PERFORMANCE PARAMETERS:

Refrigerant Power Compressor Controller Displacement Speed  Rated  Cooling  input  COP Compressor
Specifications  type Model cc/rev range speed capacity power  Height
(rpm) (rpm) W Btu/h (W) (mm）
Vertical DC12V JVB075Z12 BYC(D)12-400-4 7.5 2500-3700 3300 850 2890 340 2.50 228
DC24V JVB075Z24 BYC(D)24-400-4 7.5 2500-4500 3300 920 3128 340 2.7 228
KVB135Z24 BYC(D)24-600-2 13.5 2500-4500 3300 1780 6052 580 3.07 269
DC48V JVB058Z48 BYC(D)48-300-4 5.8 2100-5400 3600 840 2856 255 3.3 190
KVB135Z48 BYC(D)48-600-2 13.5 2500-4500 3300 1780 6052 560 3.17 269
KVB208Z48 BYC(D)48-1240-2 20.8 2500-4500 3600 2950 10030 900 3.27 260
SVB208Z48 BYC(Z)48-1240-2 20.8 2500-4200 3600 3010 10234 970 3.1 271.5
DC60-72V , JVB075Z72 BYC(D)72-400-4 7.5 2500-4500 3300 1020 3468 340 3.0 228
KVB135Z72 BYC(J)72-600-3 13.5 2500-4500 3300 1780 6052 550 3.23 269
Horizontal HB075Z12 BYC(D)12-400-4 7.5 2500-3700 3300 850 2890 340 2.50 136.5
DC24V HB075Z24 BYC(D)24-400-4 7.5 2500-4500 3300 920 3128 340 2.7 136.5
JFB132Z24 BYC(D)24-700-4 13.2 2500-4500 3300 1710 5814 570 3.0 136.5
KFB135Z24 BYC(D)24-600-2 13.5 2500-4500 3300 1780 6052 570 3.12 169
DC48V JFSB180Z48 18.0 1800-4500 3600 2500 8500 770 3.25 106
KFB135Z48 BYC(D)48-600-2 13.5 2500-4500 3300 1780 6052 570 3.17 169
KFB208Z48 BYC(D)48-1240-2 20.8 2500-4500 3600 2950 10030 900 3.27 169
SFB208Z48 BYC(D)48-1240-2 20.8 2500-4200 3600 3010 10234 970 3.1 150
DC60-72V JFSB150Z60 BYC(J)60-700-4 15.0 1800-5400 3600 2100 7140 645 3.25 106
JFSB150Z72 BYC(J)72-700-4 15.0 1800-5400 3600 2100 7140 645 3.25 106
JFSB180Z60 BYC(J)60-700-4 18.0 1800-4500 3600 2500 8500 770 3.25 106
JFSB180Z72 BYC(J)72-700-4 18.0 1800-4500 3600 2500 8500 770 3.25 106
HB075Z72 BYC(D)72-400-4 7.5 2500-5000 3300 1020 3468 340 3.0 136.5
JFB132Z72 BYC(D)72-400-4 7.5 2500-5000 4300 2300 7820 700 3.25 136.5
KFB135Z72 BYC(J)72-600-3 13.5 2500-4500 3300 1780 6052 550 3.23 169
KFB135Z72 BYC(J)72-600-3 13.5 2500-4500 4300 2370 8058 720 3.3 169
DC144V JFSB180Z144 BYC(J)144-700-4 18.0 2500-4500 3600 2500 8500 770 3.25 106
DC312V JFB132Z312 BYC(J)312-600-4 13.2 2500-4500 3300 1720 5848 540 3.2 136.5
JFSB150Z312 BYC(J)312-600-4 15.0 1800-5400 3600 2100 7140 635 3.3 106
JFSB180Z312 BYC(J)312-600-4 18.0 1800-5400 3600 2500 8500 750 3.3 106
KFB208Z312 BYC(J)312-1000-3 20.8 2400-4500 3300 2950 10030 900 3.2 169
DC220V KFA102Z220 BYC(J)220-1000-3 10.2 2400-4500 4200 3675 12495 1150 3.2 160
220V/50Hz KFA113Z220 BYC(J)220-1000-3 11.3 2400-4500 3600 3450 11730 1080 3.2 160


COMPRESSORS TESTING CONDITIONS :

EVAPORATING TEMPRETURE  CONDENSING TEMPRETURE. SUB-COOLING TEMP. AMBIENT TEMPRETURE. SUCTION TEMPRETURE.
7.2℃ 54.4℃ 46.1℃ 35℃ 35℃
