AC COMPRESSORLocation on: HOME > Products>AC COMPRESSOR

  • R22 R134a R410A COMPRESSOR (ACC 3)

    If you have any question,Please call us： jim@fluorotech.com.cn







Available for air-conditioner dehumidifier and industrial water chillers,etc.

COMPRESSOR PERFORMANCE PARAMETERS:

Refrigerant

Rate

Power

Compressor

 type

Cylinder

 capacity

 cc/rev

Cooling

capacity

input

 power

(W)

 COP

Ru

nCapacitor

 (µF/450V•AC)

Compressor

Height

(mm）
W Btu/h
R407C 1PH  220V-240V/50Hz JVC090K 9.0 1570 5338 500 3.14 20 240
JVC132K 13.2 2290 7786 790 2.90 25 263
QXC-10K 9.6 1580 5372 550 2.87 20 293
QXC-13K 13.5 2260 7684 760 2.97 25 293
QXC-16K 16.4 2760 9384 920 3.0 25 293
QXC-19K 19.2 3200 10880 1060 3.02 30 286
QXC-21K 20.8 3500 11900 1180 2.97 30 307.5
QXC-23K 23.5 3900 13260 1320 2.95 35 307.5
QXC-25K 25.4 4180 14212 1410 2.96 35 307.5
QXC-30K 30.7 5080 17272 1710 2.97 50 316.5
QXC-33K 33.6 5580 18972 1900 2.94 50 316.5
QXC-36K 35.7 5960 20264 2030 2.94 50 316.5
QXC-41K 41.2 6880 23392 2360 2.92 50 359.4
1PH  220V-240V/60Hz JVC075Y 7.5 1500 5100 500 3.0 20 247
JVC132Y 13.2 2600 8840 900 2.89 30 263
R410A 1PH 115V/60Hz JVA090T 9.0 2540 8636 910 2.8 55 250
1PH 220V-240V/50Hz JVA075K 7.5 1870 6358 650 2.9 20 250
JVA086K 8.6 2150 7310 750 2.87 25 250
JVA090K 9.0 2250 7650 790 2.85 20 250
KVA096K 9.6 2280 7752 800 2.85 20 276
KVA113K 11.3 2730 9282 960 2.84 25 276
R134a 1PH 220V-240V/50Hz JVB075K 7.5 830 2822 290 2.87 15 219
JVB092K 9.2 1050 3570 390 2.7 15 219
JVB132K 13.2 1470 4998 500 2.94 20 250
KVB096K 9.6 1100 3740 370 2.95 15 265
KVB135K 13.5 1500 5100 490 3.06 20 265
1PH 115V/60Hz JVB075T 7.5 1050 3570 350 3.0 20 219
JVB092T 9.2 1250 4250 415 3.0 15 250
JVB132T 13.2 1850 6290 615 3.0 20 263
3PH 380V/50Hz JVB132F 13.2 1450 4930 530 2.73 / 264


TEST CONDITIONS:NOTE: In developing.(The displacement could be adjusted or developed as your requirement)


APPLICATION AMBIENT TEMP. EVAP. TEMP. RETURN GAS TEMP. SUBCOOLING TEMP. CONDENSING TEMP.
HIGH TEMP 35℃ 7.2℃ 35℃ 46.1℃ 54.4℃
